7 x 10/100Mbit unmanaged switch med RJ45
3 x SFP 1000Mbit
12 - 48VDC - redundancy
-20~70°C driftstemperatur

24 ports Managed switch
20 x 10/100/1000Mbit RJ45
Supporterer IGMP Snooping
4 x 10Gbit SFP
Ethernet Ring Protection Switching

NON-MANAGED SWITCH

EH 2006,  6 ports industriswitch
6 x RJ45 10/100Mbit
Redundant PSU input.

Managed 4 x Gigabit 10/100/1000Mbit
Fiber uplink eller redundant Ring forbindelse
5 x SFP 100/1000Mbit SFP
Modbus TCP/IP for Factory Automation
Event E-mail, SNMP trap og SysLog
10.5~60VDC - redundancy
25~70°C driftstemperatur

MANAGED SWITCH

4 x Gigabit 10/100/1000Mbit
Fiber uplink or redundant Ring connection
5 x SFP 100/1000Mbit Independent SFP Link speed indication
Up to 4 x 1000M Rings for critical data stream redundancy
Modbus TCP/IP for Factory Automation
Event Notification through E-mail, SNMP trap and SysLog
10.5~60VDC power inputs - redundancy
Extended temperature range -40~75°C

Managed Gigabit Switch
administration via webbrowser og SNMP
port 1 PoE++, 60 watt. port 2-8 PoE+, 30 watt per port
4 porte for SFP fiber-transceiver
Layer 2 switch
IGMP Snooping (Multicast protokol)
Har SNMP monitor og trap
Port mirroring
-40° ~ 75° C driftstemperatur
6KV overspændingsbeskyttelse
2x PSU indgange 48-57VDC
Inkl. DIN skinnebeslag + vægmonteringsbeslag
1x relæ til alarmering

Unmanaged 8 ports switch
6 x 10/100Mbit switch
2 x SC 100Mbit Singel Mode
Power redundancy
Port and power event alarm
Dual DC10~60V power inputs
IP31 tæt
-25 70 grader C driftstemperatur

8 x 100/1000Base-SX/LX mini-GBIC SFP slots
2 x 10/100/1000Mbit RJ45
Managed switch
IP30 kabinet
DIN-skinne og vægmontering
12 to 48V DC, redundant power
Kan acceptere 24VAC
-40 to 75 Degree C driftstemperatur

8 x 10/100Mb RJ-45 ports ikke Managed switch
2 x Gigabit SC uplink ports
Broadcast storm beskyttelse
IEEE802.3x Full Duplex, back pressure flow control
Redundant dual DC power inputs
Robust kabinet
Ved fejl aktiveres relæudgang
Supporterer op til 8K MAC adresser

8 x 10/100Mb RJ-45 ports ikke Managed switch
2 x Gigabit SC uplink porte
Broadcast storm beskyttelse
IEEE802.3x Full Duplex, back pressure flow control
Redundant dual DC power inputs
Robust kabinet
Ved fejl aktiveres relæudgang
Supporterer op til 8K MAC adresser

16 x 10/100Mbit RJ45 Managed switch
2 x 1000Mbit SFP eller 10/100/1000 RJ45
Non-Blocking Switching Performance
Op til 9KB Jumbo Frame
Multiple Super Ring pattern - op til 9 Rapid Super Rings
IGMP Snooping, GMRP Rate Control for multicast message management
Modbus TCP protokol for monitering
SNMP V1/V2c/V3, RMON for remote management
Dual 24V (12-48V) DC power inputs
IP31 aluminum kabinet
-25~70°C driftstemperatur

8 ports 10/100Mbit + 2 ports Gigabit RJ45
2 x 1000BASE-X mini-GBIC SFP combo interface
PoE+ er 32 Watt (Budget er 120 Watt)
IEEE 802.3af/at End-span
Hver port giver 52VDC til PoE udstyr
Auto deteketere PoE udstyr
Giver power til maks. 100meter
Extended mode uden PoE er afstanden op til 250meter
Forsynet med smart LCD
Standard, VLAN, Extend.
