8 x 10/100Mbit RJ45 ikke managed switch med PoE port
2 x 10/100/1000Mbit RJ45 uplink ports
DC 12V~24V input
PoE på alle 8 porte - 15,4 Watt per port
Maks 65 Watt
Fejlalarm aktiverer relæudgang
-25~60℃ driftstemperatur

8 x 10/100Mbit RJ45 ikke managed med PoE
2 x 10/100/1000Mbit RJ45 uplink porte
DC 48V input
PoE på alle 8 porte - 15,4 Watt per port
Maks. er 65 Watt
Fejldetektering aktiverer relæudgang
-25~70℃ driftstemperatur

MANAGED SWITCH

4 x 10/100Mbit RJ45 PoE+ ports
2 x 10/100Mbit RJ45 redundant uplink ports
DC 48V Power Input
Up to 25 Watt per port
Up to 80 Watt total power
Multiple Super Ring technology (MSRTM), up to 5ms recovery time
Patented Rapid Dual Homing (RDHTM) technology
SNMP v1/v2c/v3, IGMP snooping v1/v2/v3, RMON, VLAN, QoS
Network security by IP/MAC address, SSL and SSH
Built-in hardware watchdog timer for system auto-reset
-40~60°C wide operating temperature

Managed Gigabit Switch
administration via webbrowser og SNMP
port 1 PoE++, 60 watt. port 2-8 PoE+, 30 watt per port
4 porte for SFP fiber-transceiver
Layer 2 switch
IGMP Snooping (Multicast protokol)
Har SNMP monitor og trap
Port mirroring
-40° ~ 75° C driftstemperatur
6KV overspændingsbeskyttelse
2x PSU indgange 48-57VDC
Inkl. DIN skinnebeslag + vægmonteringsbeslag
1x relæ til alarmering

8 ports 10/100Mbit + 2 ports Gigabit RJ45
2 x 1000BASE-X mini-GBIC SFP combo interface
PoE+ er 32 Watt (Budget er 120 Watt)
IEEE 802.3af/at End-span
Hver port giver 52VDC til PoE udstyr
Auto deteketere PoE udstyr
Giver power til maks. 100meter
Extended mode uden PoE er afstanden op til 250meter
Forsynet med smart LCD
Standard, VLAN, Extend.

8 ports Ethernet ikke managed switch 10/100 Mbit.
4 porte er med PoE - 15,4 Watt per port
4 porte er uden PoE
240VAC PSU indbygget.
Metalchassis.

4 x 10/100Mbit RJ45 Managed switch
2 x 100Mbit SC Multi Mode uplink porte
Multi-mode max. 2KM
DC 48V Power Input
Op til to 25 Watt per port
Maks. 80W total power
Multiple Super Ring technology (MSRTM), 5ms recovery time
Dual Homing (RDHTM) technology
IGMP snooping multicast
Indbygget hardware watchdog timer for system auto-reset
-40~60°C driftstemperatur

4 x 10/100Mbit RJ45 Managed switch
2 x 100Mbit SC Single Mode
Single Mode op til 30km
48VDC power input
PoE output - 25W per port
Maks. 80W total power
Multiple Super Ring technology (MSRTM), up to 5ms recovery time
IGMP snooping, multicast
Indbygget hardware watchdog timer for system auto-reset
-40~60°C driftstemperatur

Unmanaged Gigabit 10/100/1000 switch
8 ports PoE, 15,4watt/port
19” rack-beslag tilkøbes
2 porte for SFP fiber-transceiver
IGMP Snooping - Multicast
Har SNMP Monitor og Trap
Port Mirroring
100-240VAC

4 x 10/100/1000Mbit RJ45 ikke managed switch med PoE
2 x 10/100/1000Mbit RJ45 Uplink ports
PoE er 54VDC
PoE giver 30 Watt per port (4 ports)
Maks. 55 Watt total PoE
Autodetekterer PoE enheder
56VDC, 60 Watt - blæserløs
