Motherboard mini-ITX Intel Atom D525 1.8GHz Dual Ch. DDR3-800, Gibt LAN, onboard graphics, HD audio

Intel® 7th / 6th Skylake Gen-S / S-Kaby Lake Series with Q170 / H110
2 X DDR4 2400 MHz SODIMM slots up to 32GB
Triple independent displays: 2 X DVI-D, DP ( HDMI option), LVDS to 4 X GbE LAN with RJ-45
1x PCIe x16 (Gen3), 1x Mini-PCIe (Full size, with SIM Holder) slots
1 X Pattern 2 M Key, 2 x SATA 3.0 for storage
SATA RAID 0/1/5 (RAID 5 Configured with Pattern 2 M Key) to 8 X USB 3.2 Gen 1, 3 X USB 2.0, 4 X COM (4 RS-485), GPIO, Audio, System FAN
SMBus, Chassis Intrusion
Supply Voltage: 12 ~ 24V DC

Intel® 6/7th Generation Core™ Process (Max. TDP at 95W)
Intel® C236 Chipset
4 x 288-pin DDR4 2400MHz DIMM supports up to 64GB (ECC memory supported by CPU)
1 x VGA, 2 x HDMI 1.4
1 x Full size Mini PCI-e support SATA/PCI-e x1 2.0 signal) with SIM card slot
1 x PCI-e x 16, 1 x PCI-e x 4, 2 x PCI
5 x USB2.0, 8 x USB 3.0
8 x RS232
Support RAID 0, 1, 5, 10
Onboard Infineon SLB9665
support TPM 2.0ATX Power

Kompakt all-in-one blæserløst bundkort med Intel Atom processor

eller til nyeste cpu typer Core i3/i5/i7 og mulighed for Intel Vpro.

Kompakt alt-i-ét kort med sokkel til flashkort.

Bundkort med sokkel 775

Mini-ITX form factor addresses slim nettops, all-in-one PCs, thin-client PCs.
Passively cooled VIA C7 1.5GHz processor onboard.
Integrated VIA graphic engine.
Support 1 DIMM of DDR2 533MHz memory.
AC97 5.1 channel audio codec.
10/100Mbps Fast Ethernet.

EOL

ITX bundkort m/ VIA C7 CPU, u/RAM og harddisk
