Fanless Embedded Industrial PC with PCIe expansion and Intel® Core™ Ultra

IP66 NVIDIA Jetson AGX

32GB/64GB LPDDR5 memory

64 GB eMMC on module

8x GMSL2 FAKRA for cameras

4x M12 PoE GigE ports

10GbE LAN port

2x USB 2.0 ports

Waterproof USB Type-C + 4K DP

RS-232, RS-485, CAN bus

Input range of 8V to 48V DC

-40°C to 70°C operation (requires special components)

2 internal SATA for SSDs

Supports Intel® 14th/13th/12th-Gen Core™ 24C/ 32T 35W/ 65W LGA1700 CPU

1x PCIe x16 slot@Gen3, 16-lanes PCIe signals in Cassette for installing an NVIDIA® graphics card up to 130W TDP (Max. graphics card dimension is 188 mm(L) x 131 mm(W), dual slot allocation)

Support NVIDIA® RTX series GPU card up to 130W TDP

5 x 2.5GbE and 1xGbE with on special request PoE+ (ports 3~6)

1 x USB 3.2 Gen2x2 (20 Gbps) port in type-C connector with screwlock

4 x USB 3.2 Gen2x1 (10 Gbps) ports in type-A connectors

2 x USB 3.2 Gen1x1 (5 Gbps) ports in type-A connectors7 x USB 3.2

2 x USB 2.0

2 x RS232/422/485 (COM1/2), 2 x RS232 (COM3/4)

1 x Mini PCIex, 1 x Full-size mini PCI Express socket

M.2 2280 M key socket (Gen4x4) supporting NVMe SSD

Accommodates two 2.5" SATA HDD/ SSD with RAID 0/ 1 support*

1 x VGA 1920x 1200, 1 x DVI-D 1920x1200, 1 x Display port 4096x2304

MezIO™ interface for add-on expansion

CE/FCC Class A, according to EN 55032 & EN 55035

240 mm (W) x 225 mm (D) x 110.5 mm (H)

-25°C to 60°C wide temperature rugged operation (need to have special RAM and SSD)

Power suppply: DC 8~48V

GPU PC for critical setups

Intel 14th generation CPU

Integrated Intel UHD 770

NVIDIA L4 acceleration GPU

128GB ECC/DDR5 RAM

IP69K protection

Wide temperature: -40°C to 70°C (requires special components)

9V - 36V DC input

7x M12 Ethernet ports

RAID 0/1 via SATA for SSDs

Built-in power control

Can be rack and wall mounted

Compact fanless design

Intel Atom x7425E, 4 cores, 12W TDP

Supports up to 16GB DDR5 RAM

Integrated Intel UHD Graphics

3x 2.5Gb Ethernet ports

2x PoE+ ports, 50W total

2x HDMI outputs, 3840 x 2160

Serial: RS-232/422/485

4x USB 3.2 with screw lock

M.2 2280 SATA

DIN rail/wall mounting option

-25°C to 70°C (requires special components)

Edge AI computer with Jetson Orin NX/Nano

Supports 6 GMSL2 dash cams with drivers

Additional M12 GbE port for data transfer

1x RS-232

1x CAN FD port

Mini PCIe and M.2 slots for expansion

Robust design for dusty/tight spaces

Ideal for edge inspection and mobile applications

-25°C to 70°C (requires special components)

dimensions: 199mm x 136mm x 49mm

8V~35V DC input

MIL-STD-810H, Method 514.8, Category, MIL-STD-810H, Method 516.8, Procedure I

CE/ FCC Class A, according to EN 55032 & EN 55035

Compact, fanless AI computer

Intel Core Ultra 200S CPU; Supports series 35W/ 65W LGA1851 CPU

Up to 64GB DDR5 6400 memory via one SODIMM slot

Integrated Intel Xe LPG graphics

Neural processing unit for AI tasks

2x 2.5GbE Ethernet ports

4x USB 3.2 Gen 1 ports

1x software-programmable RS-232/422/485 port(COM1)

3x 3-wire RS-232 ports(COM2/3/4) or 1x RS-422/485 port(COM2)

1x HDMI, supporting 3840 x 2160 resolution

1x DisplayPort, supporting 3840 x 2160 resolution

(The DisplayPort does not support DP++. Use an active DP-to-HDMI adapter for HDMI output.)

Supports dual 4K displays

M.2 NVMe PCIe Gen4x4 slot

Internal: 1x2.5, 1x3.5 SSD/HDD bay. 1x M.2 2280 M key socket (PCIe Gen4x4) for NVMe SSD

Expansion: 2x mPCIe, 1x M.2 2230 E-key for wifi

-10°C to 60°C operation with fan

Input range of 8V to 48V DC

212 mm (W) x 165 mm (D) x 80 mm (H)

MIL-STD-810H, Method 514.8, Category 4

CE/FCC Class A, according to EN 55032 & EN 55035

Fanless Embedded PC

Intel® Core™ Ultra 200S (Arrow Lake-S),up to 24 CPU cores

CFM modules on order extra: TPM, ignition sensor, PoE

Up to 96GB DDR5 RAM

1x VGA 1920x1200 @60Hz

2x DP 4096x2304 @ 60Hz, - Support cable switch HDMI 4096 x 2160@30Hz

1x HDMI Connector : 4096 x 2160@30Hz

2x 10Gbps USB 3.2 Gen2x1, Type A

4x 5Gbps USB 3.2 Gen1x1, Type A

2x 480Mbps USB 2.0, Type A

2x RS-232/422/485 with Auto Flow Control (Supports 5V/12V), DB9

1x 2.5 GbE LAN, GbE1: Intel® I2252.5GbE & 1x 1GbE LAN

1x GbE LAN, RJ45, GbE2: Intel® I219

M.2 slots for 5G, GNSS and storage

Operating temperature: -40°C to 60°C (requires special components RAM/SSD)

Power: DC 9~48V

Fanless Embedded PC

Intel® Core™ Ultra 200S (Arrow Lake-S)

1× PCI/PCIe expansion slot

GPU / I/O card up to 75W

Up to 24 CPU cores

Up to 96GB DDR5 RAM

1x VGA, 2x DP and 1x HDMI

6x USB 3.2 and 2x USB 2.0

2x RS-232/422/485

1x 2.5GbE & 1x 1GbE LAN

M.2 slots for 5G, GNSS and storage

Operating temperature: -40°C to 60°C (requires special components)

Power: DC 9~48V
