10.4 Panel PC medico godkendt EN 60601-1
10.4 "XGA TFT LCD display with LED backlight
Intel® Celeron® processor N3060
2 Gigabit LAN to 4 USB
two COM ports, you can choose RS-232/422/485 in the BIOS
Plastic
Front IP65 close
available with support for RFID (optional)
Vesa mount, wall mount desk stand
Meets 4th EN 60601-1 (ESD contact 8KV, air 15kV)
CE, FCC certified
11,200.00 SEK
Excl. VAT
Quantity
Physically in stock
close
Specifications
| CPU | Intel® Celeron® processor N3060 up to 2.48 GHz |
|---|---|
| Chipset | SoC Integrated |
| Operating Temp. | 0°C ~ +40°C (+32°F ~ +122°F) |
| BIOS | AMI |
| Approval | EN 60601-1, CE and FCC |
| Ethernet | 2 x 10/100/1000 Mbps (Intel® i211AT) |
| Forsyning | AC version: 100 ~ 240 V AC-DC, 60W power adapter or DC version: 9 ~ 36 VDC with overcurrent protection fuse |
| IP-Tæthed | IP65, NEMA 4 rugged protection, plastic front bezel |
| LCD | 10.4" XGA TFT 350 nits 1024 x 768 pixels |
| Lyd | Line-out |
| Montering | VESA arm Panel mount Desktop stand |
| OS SUPPORT | Windows® 10, Windows® 8.1, WE8S, Windows® 7, WES7 |
| Porte | 1 x RS-232 1 x RS-232/422/485 (default RS-232) |
| Touch | Resistive Type |
| Udvidelser | 1 x full-size PCI Express Mini Card slot with mSATA slot 1 x full-size PCI Express Mini Card slot with SIM slot |
| Watchdog | 255 levels, 0 ~ 255 sec. |
| Weight | 1.8KG |
| Dimensioner | 292.5 x 45.8 x 235.8 mm (11.52" x 1.80" x 9.28") (W x D x H) |
IPP10.4Medic is powered by Intel® Celeron® processor N3060 with fanless and silent operation. 10.4-inch XGA TFT LCD with resistive touch and 350 nits brightness. IPP10.4Medic is certified for medical applications and is designed to be integrated with care vehicles and medical devices as a terminal for care or infotainment terminal. IPP10.4Medic meets the requirements of the latest version of EN 60601-1. Its mechanical design has passed the ESD immunity test with 15 kV air discharge and 8 kV contact discharge to ensure operational safety in the challenging health environment. In addition, its lightweight and ultra-thin design with a thickness of 45.8 mm provides excellent space efficiency and greatly improves mobility and flexibility. Because of its fanless design, the 10.4 "medical PC offers reliability, zero maintenance cooling costs, and proves valuable for noise-sensitive environments such as the patient center, nursing station and clinic
