Double electronic door magnet for 12 / 24VDC with switching. Indoor double doors. Holding force up to 2 x 545 kg
Electronic door magnet for double-doors, whop door etc.
Holding power up to 545 kg for each door
Aluminum House and Vandalsproof
Supply voltage for team: 12VDC or 24VDC, minimum 2 x 6 watts
Automatic switching between 12 and 24VDC
No holding power at voltageless
Operating temperature: -10 - 55 ° C
humidity: 0-95% non-condensing
double magnet: 533 x 71 x 40 mm
Door plates: 185 x 61 x 16 mm
Double mounting plate: 533 x 40 x 8 mm
Weight: approx. 5.6 kg
Buy access system - see accessories
5,830.40 SEK
Excl. VAT
Quantity
close
Door-magnet-SLI25 is used for wing doors, swing doors, double doors o.li., where an electronic locking plate cannot be installed. Door-magnet-SLI25 can be used with most access control controls that have single or double relay output. The product contains 2 powerful electromagnets that "lock" themselves to the piece of metal mounted on the respective door. When there is voltage on Door magnetic SLI25, the door cannot be opened. An access control connected to Door-magnet-SLI25 accepting e.g. A password will interrupt the voltage to the magnetic coil and the magnets release so that the doors can be opened. Holding force: 2 x 545 kg. Automatic switching between 12VDC and 24VDC voltage to the holding magnet. Estimated power consumption is a minimum of 12watt. Since the electromagnets are supplied with voltage in hold mode, the power supplies for door magnetic SLI25 should supply at least the dual power (25 - 50watt), this to minimize heat generation in the power supply.
